Catalogue #1

T25/Vanagon Cluster PCB from model year '85

For all T3 from model year 1985. Suitable for all diesel and gasoline engines. In the set are all parts that are needed. Perfect replacement for the defective T3 speedometer foil. This is a kit with a prefabricated circuit board and all necessary components. On the board all components are already assembled in SMD. Nothing more has to be soldered. The kit also comes with a prefabricated cable set. The instructions can be found here on my site. This kit can be used as an alternative for the VW spare part numbers 251 919 059 A/B/C/D/E/F/G/K. The kit was designed for easy installation. Nevertheless, the installation should be done by skilled personnel. ATTENTION!!! Please have a look into the manual before buying!!! If something should be unclear, then please use the contact form for your questions.

Delivery time

Product number T3-CL-PCB-85

€169.00*

Details

Digital Clock LCD Screen

Repair kit for the digital clock display suitable for VW T3 various VW Golf 2 and other VW models. Often the LCD of the digital clock in the cockpit is partially or completely leaked. Remedy is then only a completely new clock or the replacement of the LCD. In the scope of supply are also new ladder rubbers included PLEASE NOTE: Replacing the LCD does not fix any faults in the wiring or electronics. The installation should not be done by laymen

Delivery time

Product number LCD-T3

€36.00*

Details

Speedpuls 8P

Signal generator for a digital speedometer signal. The 8P module generates 8 electrical pulses per speedometer shaft revolution. With a k-number of approx. 500 (T3-2WD), this results in 4000 pulses per revolution. 2WD speedometer: W=500 ⇢ 500 speedometer shaft revolutions per km ⇢ with 8P module ⇢ 4000 pulses per km 4WD speedometer: W=1000 ⇢ 1000 speedometer shaft revolutions per km ⇢ with 8P module ⇢ 8000 pulses per km Depending on the control unit/signal processor unit used, a tachometer signal can be generated with 5V or 12V. Via a solder bridge, the signal voltage can also be adjusted subsequently.

Delivery time

Product number SP-8P-12V

€74.00*

Details

T25/vanagon Cluster PCB for yellow high beam

Custom made for T3's with yellow LED for the high beam. For all T3's up to model year 1984 which have a yellow high beam control registered. Suitable for all diesel and gasoline engines. In the set are all parts that are needed. The perfect replacement for the defective blue circuit foil. This is a kit with a prefabricated circuit board and all necessary components. On the board all components are already assembled in SMD. Nothing more has to be soldered. The kit also comes with a prefabricated cable set. The instructions can be found here on my site. This kit can be used as an alternative for the VW spare part numbers 251 919 059 A/B/C/D/E/F/G/K. The kit was designed for easy installation. Nevertheless, the installation should be done by skilled personnel. ATTENTION!!! Please have a look into the manual before buying!!! If something should be unclear, then please use the contact form for your questions.

Delivery time

Product number T3-CL-PCB-84-GELB

€189.00*

Speedpuls 4P

Signal generator for a digital speedometer signal. The 4P module generates 4 electrical pulses per speedometer shaft revolution. With a k-number of approx. 1000 (T3-Syncro, Golf2, etc.) this results in 4000 pulses per revolution. 2WD speedometer: W=500 ⇢ 500 speedometer shaft revolutions per km ⇢ with 4P module ⇢ 2000 pulses per km 4WD speedometer: W=1000 ⇢ 1000 speedometer shaft revolutions per km ⇢ with 4P module ⇢ 4000 pulses per km Golf MK2 speedometer: W= 960 ⇢ 960 speedometer shaft revolutions per km ⇢ with 4P module ⇢ 3840 pulses per km Depending on the control unit/signal processor unit used, a tachometer signal can be generated with 5V or 12V. Via a solder bridge, the signal voltage can also be adjusted subsequently.

Delivery time

Product number SP-4P-5V

€74.00*

Details

T25/Vanagon Cluster PCB until Model Year '84

For all T3 up to model year 1984. Suitable for all diesel and gasoline engines. Not suitable for models with yellow high beam LED! In the set are all parts that are needed. The perfect replacement for the defective T3 speedometer film. This is a kit with a prefabricated circuit board and all necessary components. On the board all components are already assembled in SMD. Nothing more has to be soldered. The kit also comes with a prefabricated cable set. The instructions can be found here on my site. This kit can be used as an alternative for the VW spare part numbers 251 919 059 A/B/C/D/E/F/G/K. The kit was designed for easy installation. Nevertheless, the installation should be done by skilled personnel. ATTENTION!!! Please have a look into the manual before buying!!! If something should be unclear, then please use the contact form for your questions.

Delivery time

Product number T3-CL-PCB-84

€169.00*

Instrument Cluster Repair Corners

This repair corner was specially designed to repair the broken corners on the T25/Vanagon instrument cluster. In all the instrument cluster housings I have seen so far, the corners were torn or partially torn out. As soon as the thread is no longer present, it becomes very difficult to fix the speedometer or tachometer reasonably. Remedy is this corner. They are attached to the housing with a little super glue or with 2K glue. This gives the screws a hold again. These corners are printed from ABS.

Delivery time

Product number T3-CORNER1

€6.00*

Instrument carrier repair corners

Repair corners for the instrument holders. If on the tabs the instruments (speedometer, tachometer or analog clock) are broken off, they can be replaced with these corners. These corners are printed from ABS and can be fixed with a little super glue or 2K glue.

Delivery time

Product number T3-CORNER2

€3.00*
